Elite Robots CPF10-CS530H Collaborative Palletizing Workstation 30kg Payload 1522mm Reach Cobot for Carton Bag Stacking

Name: Elite Robots CPF10CS530H Collaborative Palletizing Workstation 30kg Payload 1522mm Reach Cobot for Carton Bag Stacking
Brand: Elite
Price: 42 USD

Quality Elite Robots CPF10-CS530H Collaborative Palletizing Workstation 30kg Payload 1522mm Reach Cobot for Carton Bag Stacking for sale

Place of Origin : Shanghai, China

Compatible Product Type : conveyors, Sensors, grippers, vision systems, end effectors

video outgoing-inspection : Provided

Axis : 6

Warranty : 1 Year

power(w) : 1 kW(1.34hp)

production capacity : 50 sets per month

voltage : 380 V

MOQ : 1

IP classification : IP44

Payload : 30 kg

application : handling, palletizing

dimension(l*w*h) : 180*150*160cm(70.87*59.06*62.99in)

Product Name : Cobot Palletizing Workstation CPF10

Repeatability : 0.1 mm

I/O port : 24 DI/DO; 2AI/AO

weight (kg) : 120

Communication : Ethernet, Modbus TCP/RTU, Ethernet/IP slave, Profinet slave

core components : PLC, Engine, Motor

Arm reach : 1522 mm

machinery test report : Provided

Material : Aluminum, Alloy, TPE

Price : $42,130

Brand Name : Elite

Robot Model : CS630H

Fixed Column : 1000 mm

Contact Now

Product descriptions from the supplier

30kg Heavy Duty Palletizing Performance: Equipped with CS530H 6 axis heavy payload cobot arm, 30kg payload, 1522mm reach. Max stacking height 1600mm, compatible with pallet size up to 1200*1000mm Zero programming Operation: Built in dedicated palletizing wizard on 12.1-inch touch teach pendant.

Switch between different palletizing tasks within 1 minute; full system redeployment completes within 10 minutes. Human Robot Collaborative Safety: Fully complies with ISO 10218, ISO 13849, ISO/TS 15066 standards.

Optional safety scanner with reduced speed & safety stop function, no mandatory physical safety fence Compact Modular Fixed Column Structure: Small 1400*1700 mm footprint. Independent service friendly control cabinets.

Easy relocation between production lines without large scale factory reconstruction Flexible End effector Compatibility: Supports single / dual vacuum cup EOAT. Stable for cartons, woven bags and packaged goods for end of line stacking tasks.

Robot arm IP65 rated for harsh workshop conditions Ultra fast On site Commissioning: Initial setup finished in less than 1 hour. Single-phase 110-220VAC power supply, operating temperature 0-50℃. Short ROI within 12 months.

Rich Industrial Communication: Supports Modbus TCP/RTU, Ethernet/IP, Profinet slave. Widely adopted in food, chemical, hardware and general manufacturing end-of-packaging lines.
